FDT940A 10W 60km wireless hopping drone telemetry module

Product description: T940A is mainly used for data transmission of high-power long-distance industrial drones. It has small size, good integration, high sensitivity, and weighs only 200g. The working frequency band of T94
INQUIRY

T940A is mainly used for data transmission of high-power long-distance industrial drones. It has small size, good integration, high sensitivity, and weight is 200g only. The working frequency band of T940A is 902~928MHz. T940A adopts 256-bit physical layer encryption, the transmission data is stable and not easily disturbed.

Specifications:

Frequency range: 902-928MHz
Spread spectrum method: FHSS
Data Encryption: 256-bit physical layer encryption
Communication range: up to 100KM/200KM
Output power: 10W (40dBm)
Air interface rate: up to 276.4kbps
Serial port baud rate: up to 921.6kbps
Operating temperature: -40°C to 85°C
Power supply voltage: DC15~26V, typical value +24V
Size: 102*49*18.5mm
Weight: 200g
