Agriculture drones sprayer catalogue

  • 8 roter 22L drone sprayer
  • 8 roter 22L drone sprayer
8 roter 22L drone sprayer8 roter 22L drone sprayer

8 roter 22L drone sprayer

  • Product description: FDXD-8R-22L drone sprayer is Flydragon UAV company's new agriculture drone for 2020, max takeoff weight is 55KG, payload 22L, flight time is 15 minutes, effective working area is 4 acres
  • INQUIRY

8 roter 22L drone sprayer

FDXD-8R-22L drone sprayer is Flydragon UAV  company's new agriculture drone for 2020, foldable design easy to delivery FDXD-8R-22L drone sprayer max takeoff weight is 55KG, payload 22L, flight time is 15 minutes, effective working area is 4 acres each flight with 2 pieces 12S 16000mah

Specifications

---------------------------------------------------------------------
---------------------------------------------------------------------
Frame Recommended configuration

Wheelbase :2122mm

Motor:X8

Expand Size :2050*2050*643mm

Propeller:28-30inch

Folded size :1107*1107*643mm

ESC:80A FOC

Tank capacity: 11L*2

Input Voltage: 12S

Frame Kit weight :14kg( Without spraying system )

MTOW:55kg

Pump

Size:85mm*66mm*58mm

Power:180W

Weight:300g Maximum

Flow rate :5.5L/min

Input voltage :43~60V

Stroke range :1100-1900μs

Maximum current :3A

Pressure :0.58Mpa
