Vanguard lithium ion battery pack and hybrid generator for drone


5kwh lithium-ion battery rugged battery pack Vanguard's lithium-ion battery pack is very suitable for a wide range of commercial and military UAV, UGV, USV and UUV platforms, and can provide general and efficient solutions to meet the exact requirements of users. The latest fully integrated system has an internal battery management system (BMS) that can work seamlessly with CANbus-controlled chargers and communication networks. The modular nature of battery packs allows them to be easily configured for various capacities and voltages, and multiple batteries can be stacked to provide the required power level.


Vanguard's battery pack has three basic configurations of 3.8 kWh, 5 kWh and 10 kWh, which can provide multiple advantages for drones and unmanned driving systems. Vanguard's V-Twin horizontal axis gasoline generator has an output option of 17.2 to 29.9 total kW (23 to 40 total HP), which is an ideal choice for various UAVs and UAV platforms.

Advanced electronic fuel injection (EFI) technology can automatically adjust all operating points of the engine and monitor a series of on-board sensors to determine how much fuel and spark to provide and when to provide the engine cycle by cycle. The result is improved driving performance at all temperatures, stable operation at any altitude, rapid response to load changes, and greatly improved fuel consumption efficiency.

The company's latest 29.9 total kilowatt (40.0 total HP) engine also uses the latest electronic throttle control (ETC) technology, which enables the engine to quickly detect any changes in RPM, thereby responding immediately to any load imposed in the environment. By maintaining power output, you can also maintain a consistent engine speed, thereby improving efficiency.


FlyDragon 2400W hydrid generator for drone

Hybrid Power System for drone FLY2400 generator is a high efficiency generator designed for multicopters. FLY2400 generator is only 4.2kg which is much lighter than any other generators that produce 2400w output power, so FLY2400 generator is five times the efficiency of other generators. The continuous power output of generator is 2000w. An internal combustion engine consumes gasoline and spins a generator to ensure a 48V output. Besides this, a 12S lipo battery package is also needed to be installed onboard to offer emergency back-up power for quick climbing and quick maneuvering. With this generator, the max take-off weight can reach 19kg(according to your power system), and the max flight time is about 5 hours.  FLY2400 generator is suitable for those multicopters whose power is still lower than 2000w even with 6kg generator system(including generator, fuel tank and 1L gasoline). As for the fuel, the auto gasoline is available. When the generator running, its noise level is about 80 dBA. But the noise has no effect if you talk 10 meters away from the drone. We also provide the silencer if you need which could reduce the noise to 60 dBA.
Also maintenance is necessary for FLY2400 to keep its high performance. The maintenance cycle is 50 hours. And we will also provide the accessories for generator maintenance.

Specifications:

Weight: 4.5kg
Size: 201*258*161mm (LxWxH)
Applicable models: Multirotors/VTOL Fixed Wing
Max take-off weight: 18kg
Power voltage: 12S
Fuel consumption: 600g/kW*h (Hovering 1.5L/h)
Working Temperature: -20℃-40℃
Theoretical ceiling (Altitude): 1000m
Petrol: 95# or above (petrol+2T lubricant two-stroke lubricants that meet JASO FC/FDIOS-L-EGD standards)

Main Features:

1. Integrated design of Start up and power generation,and the air start function can be realized without relying on external starting equipment.
2. The one-piece design allows for easy suspension in all types of Frame kit and a variety of mission load suspensions on the bottom.
3. No need charge preparation time, no complicated ignition action, it can quickly perform tasks.
4. The backup battery can provide power for emergency short-range return or forced landing in an emergency.
5. For light load service, additional fuel tanks can be added to expanded to flight time to 4-6 hours.
6. Quick and easy engine installation method, conveneient to replace and maintain.

Package Included:

Hybrid powertrain x 1
6s 4000mah battery x 2
Starter x 1
Controller x 1
Spark plug wrech x 1 (Gift)
Petrol Proportional bucket x 1 (Gift)

Download User Manual

MAINTENANCE CHART

 Items  Action Before Use Every 25 hours Every 100 hours  Note
Leakage,Damage/Crack Check  ✔
Idling Speed Check/Adjust ✔ ✔ ✔
Air-cleaner Check/Cleaning ✔ ✔ Replace if necessary
Spark Plug(gap) Check/Adjust ✔ ✔ ­
Cylinder(barrel) Check/Cleaning ✔ ✔ ­
Piston, Ring Check/Cleaning ✔ ✔ ­
Bolt Check/Cleaning ✔ ✔ ✔ ­
Bearings Check/Cleaning ✔ ✔

FlyDragon 7000W hybrid genrator system for drone

specification

Size: 270*360*272mm (LxWxH)
Rated voltage :MIX 51.8V MAX 58.5V 14S
Continues power: 6000W
Weight: 12 kg
Fuel consumption : 9.5L/H
Fuel ratio: 25:1 (95# gasoline, FD grade 2T oil)
Working temperature: -20~45 degrees Celsius
Startup mode: one-button self-starting
Cooling method: water cooling

FL7000 advantages:
1: Intelligent cooling system: It can reduce heat consumption according to the high and low temperature of the engine cylinder.
2: LED intelligent display, real-time accurate display of speed, voltage, cylinder temperature and system status.
3: One-piece patented industrial design, dustproof and waterproof, easy to maintain.

Features
The integrated power generation design is started, and the air start function can be realized without relying on external starting equipment.
The one-piece design makes it easy to hang in all types of racks.
No need to charge preparation time, no complicated ignition action, can quickly perform tasks.
In a cold environment of -20 degrees Celsius, it can work stably.
The backup battery can provide power for emergency short-range return or forced landing in an emergency.
For light-load business, additional fuel tanks can be added and the range can be increased to 1.5-3 hours.
Quick and easy engine installation for quick and easy engine replacement and maintenance.

Flydragon 23KW hybrid power system

Specifications:

Weight: 39.5kg
Applicable models: Multirotors
Max take-off weight: 100kg
Power voltage: 24S
Fuel consumption: 17.5L/H
Working Temperature: -20℃-40℃
Theoretical ceiling (Altitude): 1000m
Fuel ratio: 0-5 hours 25:1; after 5 hours 50:1 (95# gasoline, FD grade 2T engine oil)

Main Features:

1. Integrated design of Start up and power generation,and the air start function can be realized without relying on external starting equipment.
2. The one-piece design allows for easy suspension in all types of Frame kit and a variety of mission load suspensions on the bottom.
3. No need charge preparation time, no complicated ignition action, it can quickly perform tasks.
4. The backup battery can provide power for emergency short-range return or forced landing in an emergency.
5. For light load service, additional fuel tanks can be added to expanded to flight time to 3 hours.
6. Quick and easy engine installation method, conveneient to replace and maintain.
