FD4100 six axis carbon fiber drone frame

FD4100 six axis carbon fiber drone frame

  • Product description: FD4100 is a long flight time six axis carbon fiber drone Frame , FD4100 is made of carbon fiber material which features light weight and high strength, The arm of FD4100 is pluggable, both the cover
  • INQUIRY

FD4100 six axis carbon fiber drone Frame

FD4100  is a long flight time six axis carbon fiber drone Frame , FD4100 is made of carbon fiber material which features light weight and high strength, the canopy of FD4100 is made of glass fiber so that the GPS signal won’t be blocked. The closed fuselage structure can protect FD4100 from the rain and dust, and also protect other load equipments like flight control and battery. The arm of FD4100 is pluggable, both the cover and arms can be locked with the quick locking hooks. Due to its detachable arm the FD4100 drone Frame is also easy to carry.
FD4100 can be applied in many fields like aerial photography, emergency rescue, reconnaissance mission, power line inspection, remote sensing survey and mapping etc.

Specifications:

– Wheelbase:1200mm
– Weight: 1750g(frame only)
– Max payload: 6kg
– Flight time:  70min (2 pieces of 25000 mAh li battery,   without any payload)

drone Frame Features:

– TORAY 3K Carbon fiber material
– Light-weight, durable and stable
– Rainrproof
– Long flight time
– Detachable arm, easily portable

Options:

– Motor: T-MOTOR 6 series , DJI2000
– Propeller: 22 inch
